Flat Cylinder
Application-engineered for demanding process-plant duty.
Flat low-profile cylinders are purpose-built for installations where axial clearance is severely restricted, such as limestone reclaim gates, deck-plate diverters, and compact clamping stations.
6 engineering parametersAlternate Views:
Application detail
Designed around plant conditions.
Retains full rated hydraulic force and stroke within an ultra-flat envelope, utilizing heavy-duty wipers and poly-step seals to block clinker dust and abrasive fines.
Final bore, stroke, mounting, material and seal selection are confirmed against the approved drawing and operating duty.
Technical range
6 parametersFlat Cylinder specifications
| Parameter | Indicative specification |
|---|---|
| Bore Size | 63-250 mm |
| Stroke Length | 50-800 mm |
| Working Pressure | 160-250 bar |
| Profile | Low-height, flat body design |
| Mounting | Foot / flange, side-lug |
| Seals | Wiper + PU rod seal for dust-prone areas |
