Customized Cylinder
Clean, low-friction air actuation built to industrial ISO standards.
Tailor-made pneumatic cylinders engineered to exact customer specifications - custom stroke lengths, special rod extensions, non-standard mounting configurations, and high-temp or heavy-duty seal options.
Tested at 1.5x Rated PressureAlternate Views:
Engineering detail
Tested at full pressure before dispatch.
Each pneumatic cylinder is assembled under controlled cleanroom conditions and subjected to full-stroke cycle testing at rated operating pressure with adjustable end-cushion verification.
Available with custom mounting clevises, high-temperature Viton seals, magnetic reed switches, and food-grade lubricants.
Technical specifications
6 parametersCustomized Cylinder Parameters
| Parameter | Specification |
|---|---|
| Custom Bores | 12 - 500 mm |
| Stroke Range | Custom up to 4,000 mm |
| Special Mountings | Custom Clevis, Flange, Trunnion, Foot |
| Seal Options | Viton, Teflon, FDA-compliant NBR |
| Duty Cycle | Severe duty / Heavy process environments |
| Operating Pressure | Up to 15 bar |
